Small Gasoline Vehicle Mounted Fuel Dispenser Explosion Proof Oil Well Pump

Name: Small Gasoline Vehicle Mounted Fuel Dispenser Explosion Proof Oil Well Pump
Brand: FIMEET
SKU: BJJ-20-AH1
Price: 1 USD
Availability: InStock
Rating: 4.9 (155 reviews)

Product Details

Place of Origin: Anhui, China

Brand Name: FIMEET

Certification: ISO9001

Model Number: BJJ-20-AH1

Payment & Shipping Terms

Minimum Order Quantity: 1 Piece

Price: $1,200.00(1 - 4 Pieces) $980.00(>=5 Pieces)

Packaging Details: 1 set/wooden box or OEM package

Supply Ability: 10 Set/Sets per Day

Get Best Price

Product Details

Product Description

Highlight:

Warranty:	1 Years	Customized Support:	OEM
Brand Name:	FIMEET	Model Number:	BJJ-20-AH1
Place Of Origin:	Anhui, China	Application:	Other, Automotive Industry, Industrial Utilities
Horsepower:	750w	Power Source:	Electric
Pressure:	0.3MPa	Structure:	Gear Pump
Cable Length:	3	Outlet Size:	1'
Voltage:	AC220/380V, AC220/380V	Power:	0.75KW, Electric
Usage:	Diesel Oil, Gasoline	Fuel:	Gasoline
Theory::	Rotary Pump	Available Oil::	Diesel/kerosene/gasoline/methanol
Flow Range::	20-80L/min	Accuracy::	Â±0.2%
Max.work Pressure::	3BAR	Single Gauge Number::	1-99999.9L
Certification:	ISO9001

Warranty:	1 Years
Customized Support:	OEM
Brand Name:	FIMEET
Model Number:	BJJ-20-AH1
Place Of Origin:	Anhui, China
Application:	Other, Automotive Industry, Industrial Utilities
Horsepower:	750w
Power Source:	Electric
Pressure:	0.3MPa
Structure:	Gear Pump
Cable Length:	3
Outlet Size:	1'
Voltage:	AC220/380V, AC220/380V
Power:	0.75KW, Electric
Usage:	Diesel Oil, Gasoline
Fuel:	Gasoline
Theory::	Rotary Pump
Available Oil::	Diesel/kerosene/gasoline/methanol
Flow Range::	20-80L/min
Accuracy::	Â±0.2%
Max.work Pressure::	3BAR
Single Gauge Number::	1-99999.9L
Certification:	ISO9001

Small Gasoline Vehicle Mounted Fuel Dispenser Explosion Proof Oil Well Pump

Product Description

Product Application

Owns many patents, which is developed by Anhui ruiling meter manufacturing co.,ltd. This model of fuel dispenser is widely used in industrial and mining enterprises, middle and small oil depot, gas station for transporting diesel and kerosene etc. This Anti- Explosion fuel dispenser owns many advantages, for instance, reasonable design, compact structure, small and fine, convenient for carry, high accuracy, big flow rate convenient for usage, easy for maintenance, and so on.

Our design is much more compact, layout is more reasonable,increasing the operation efficiency.

SPECIFICATIONS FOR GASOLINE FUEL DISPENSER
Model No.:	AH1/AH1D	Accuracy:	±0.5%
Flow range:	20-60L/min/20-80L/min	Max.pressure:	4 Bar
Voltage:	AC 220v/380v	Single Range:	0.0-99999.9L
Suction/Lift:	25m/25m	Accumulative Range:	0-99999L
Total weight:	75kg/78.5kg	Range of Price:	0.00-$99.99
Temperature range:	-20°c-50°c	Total Amount Range:	0-$99999
Inhalation caliber:	25mm	Measure Minimum:	5L
Discharge caliber:	20mm	Size:	550485720mm
Medium	Gasoline, Petrol, Diesel, Kerosene, Water, Methanol and other liquid.

Main Features

For the reason that our First generation mechanical fuel dispenser has been copied, our company updated the products series with 10 updated points under the price not increased.

1. More attracting appearance;
2. Increasing the thickness of the shell;
3. Good at Resistant high temperature: 50℃ Test;
4. With functions of integer and non integer quantitative refueling;

5.The standard of excellent accuracy measuring accuracy can reach 0.2%;
6. Professional All of our fuel dispenser are Anti-Explosion type design;
7. Two way control valves to ensure the precise control of a small amount of fuel;

8. Our design is much compact, layout is more reasonable, increasing the operation efficiency;
9. With Double-layer steel wire mesh, wear-resisting, corrosion resistance, pressure resistant tubing;
10. Choosing new type electromagnetic switch,greatly enlarging using safety and stability and prolong the using life.

Factory Show

Canton Fair

120th Canton Fair

Meet every year of Canton Fair

121th Canton Fair

and Still to be continued......

122th Canton Fair

Detailed Images

Machine Parts

Name: Anti-Explosion Gasoline Fuel Dispenser;

Brand: FIMEET;

6 Digits LCD Display;

Show Unit Price, Total Amount, Total Volume.

Machine Parts

Lift Handle;

All English and Arabic Numeral Panel;

3 Version of Computer Motherboards, Work Independently;

All-Round Visual Mirror, Monitoring Fuel Volume At Any Time.

Machine Parts

Lock With Metal Key;

Two Levels: Button Switch;

Design Power Light, Transmit Electricity Situation;

Design Emergency Button, Control Risk At Any Time.

Internal Structure

F Class Insulation;

T4 Anti-Explosion Pump;

Solenoid Valve Control System;

High Accuracy 4 Cylinder Piston Flowmeter.

Standard Configuration

1 Set Manual;

2M Inlet Pipe;

5M Output Pipe;

1 Set 11A Automatic Fuel Nozzle.
